????️ Network Dome Camera – Model IPC-T221H-LC

The IPC-T221H-LC is a compact and high-performance network dome camera designed for reliable indoor or outdoor surveillance. With Full HD resolution, smart IR, and robust housing, it offers a balanced mix of clarity, durability, and smart functionality for modern security systems.

???? Technical Specifications

• Model: IPC-T221H-LC

• Image Sensor: 1/2.8" Progressive Scan CMOS

• Resolution: 1920 × 1080 (Full HD 1080p)

• Frame Rate: 25/30 fps at 1080p

???? Lens & Viewing Angle

• Lens Type: Fixed lens

• Focal Length: 2.8mm

• Horizontal FOV: Approximately 106°

• Wide-angle lens ideal for monitoring broad areas such as entrances, hallways, or storefronts

???? Infrared Night Vision

• IR Distance: Up to 30 meters (98 feet)

• Smart IR: Prevents overexposure and ensures balanced lighting in complete darkness

• Clear visibility day and night with auto IR cut filter

???? Audio Functionality

• Audio Support: Built-in microphone (1-way audio)

• Captures ambient sound for increased surveillance effectiveness

???? Design & Construction

• Camera Type: Dome

• Color: White

• Material: Sturdy plastic and metal housing

• Mounting Options: Ceiling or wall mount with 3-axis adjustment

???? Connectivity & Compression

• Network Interface: RJ45 10M/100M Ethernet

• Video Compression: H.265+, H.265, H.264+, H.264

• Low bandwidth and storage consumption without sacrificing video quality

⚡ Power & Power Consumption

• Power Supply: 12V DC ±25% or PoE (Power over Ethernet, IEEE 802.3af)

• Power Consumption: Max. 4W

• Flexible installation with single-cable PoE support

????️ Environmental Protection

• Weatherproof Rating: IP67

• Operating Conditions: -30°C to 60°C (-22°F to 140°F)

• Reliable performance in rain, dust, and extreme temperature environments

????️ Additional Features

• Motion detection and event triggers

• Image enhancements: Digital WDR, 3D DNR, BLC

• Secure access and configuration via web interface

• ONVIF compatibility for integration with standard NVRs and VMS platforms

Perfect for residential, commercial, or light industrial applications, the IPC-T221H-LC delivers consistent Full HD surveillance with smart features to enhance situational awareness and site security.
